FRAME
ONE-SIXTY CF4 III
171mm suspension travel mullet / 162mm suspension travel 29"
material: carbon
29x2.5" max. wheelsize
148x12mm axle standard
BSA bottom bracket standard

FORK
Rock Shox Zeb Ultimate
Air
170mm suspension travel
Tapered
42mm fork offset
29x2.8" max. wheelsize

SHOCK
Rock Shox Super Deluxe Ultimate
platform
adjustable low speed compression

BRAKES
Shimano XT

ROTORS
Shimano RT86

HEADSET
MERIDA 8151

HANDLEBAR
MERIDA TEAM TR

HANDLEBAR STEM
MERIDA EXPERT eTRII

GRIP
MERIDA EXPERT EC

DERAILLEUR (R)
Sram GX Eagle AXS

SHIFTERS
Shimano SL -MT800-IL / Sram GX AXS Controller

SEAT POST
MERIDA TEAM TR

SEAT CLAMP
MERIDA EXPERT

SADDLE
MERIDA EXPERT SL

CHAIN
Sram GX

CHAINGUARD
MRP AMg V2 Alloy 26-32T

CRANK
Sram X1 Carbon
32 teeth
170 mm for
FREEWHEEL Sram XG-1275 Eagle
10-52 teeth
12 speed

BOTTOM BRACKET
Sram BB DUB BSA 73 MTB WIDE

WHEELSET
Race Face Turbine R30
110x15mm width front hub
148x12mm width rear hub
28mm inner width
Centerlock
Sram XD
material: aluminium
Tubeless ready (tubeless tape and valves included)
Lifetime warranty
rear 27.5" up to Size M, rear 29" L & XL

TYRE FRONT
Maxxis Assegai
29x2.5"
fold
TR DD 3C MaxxGrip

TYRE REAR
Maxxis DHR II
27.5x2.4" XS/S/M 29x2.4" L/XL
fold
TR DD 3C MaxxTerra

AXLES
MERIDA EXPERT TR

FENDER
Rock Shox ZEB Fender

WEIGHT
15.3 kg

MAX. WEIGHT
135 kg
