FRAME
ONE-FORTY CF4 III
143mm suspension travel 29"
material: carbon
29x2.5" max. wheelsize
148x12mm axle standard
BSA bottom bracket standard

FORK
FOX 36 Float Performance Elite
Air
150mm suspension travel
Tapered
44mm fork offset
29x2.6" max. wheelsize

SHOCK
FOX Float DPS Performance Elite
adjustable low speed compression
plateform

BRAKES
Shimano XT

ROTORS
Shimano RT86

HEADSET
MERIDA 8151

HANDLEBAR
MERIDA TEAM TR

HANDLEBAR STEM
MERIDA EXPERT eTRII

GRIP
MERIDA EXPERT EC

DERAILLEUR (R)
Sram GX Eagle AXS

SHIFTERS
Shimano SL -MT800-IL / Sram GX AXS Controller

SEAT POST
MERIDA TEAM TR

SEAT CLAMP
MERIDA EXPERT

SADDLE
MERIDA EXPERT SL

CHAIN
Sram GX

CHAINGUARD
MERIDA EXPERT TR ISCG05

CRANK
Sram X1 Carbon
32 teeth
170 mm-S, 175 mm-M up

FREEWHEEL
Sram XG-1275 Eagle
10-52 teeth
12 speed

BOTTOM BRACKET
Sram BB DUB BSA 73 MTB WIDE

WHEELSET
Race Face Turbine R30
110x15mm width front hub
148x12mm width rear hub
28mm inner width
Centerlock
Sram XD
material: aluminium
Tubeless ready (tubeless tape and valves included)
Lifetime warranty

TYRE FRONT
Maxxis Minion DHF
29x2.5"
fold
TR EXO 3C MaxxTera

TYRE REAR
Maxxis Dissector
29x2.4"
fold
TR EXO MaxxTerra

AXLES
MERIDA EXPERT TR

FENDER
FOX 36 fender

WEIGHT
14.65 kg

MAX. WEIGHT
135 kg
